Description
Features
- The bearings are particularly suitable for applications with a very small radial section height on account of their very low cross-sectional height
- Used if the housing bore is not suitable as a raceway for needle roller and cage assemblies
- Can support high radial loads
- Require a considerably smaller radial design envelope than machined needle roller bearings
- Usually run directly on the shaft
- Permit relatively high speeds
- Easy to mount
- Require no additional means of axial retention
- Can be readily used to close off the shaft ends of bearing positions
- Result in particularly compact, cost-effective and economical bearing arrangements
- AS1 with lubrication hole from HK0609
- 11000 N dynamic/15200 N static
Technical Specifications
- Cage Material : Sheet Steel
- Closure Type : Open
- Maximum Speed : 10200 rpm
- Series : HK Series
- Temperature Rating : -30 to 140 deg C
- Bore Diameter : 25 mm
- Outside Diameter : 32 mm
- Number of Rows : 1
- Width : 12 mm
- Load Capacity : 15200 N
Replaces KTM/Husqvarna Parts
- 0617253212
